- Drive: Stepper motor
- Force measurement:: Load Measurement Cell (LMZ)
- Measurement principal: Pressure Load Cell (DMS)
- Force unit: N, Kp or Sc
- Measuring range: 4-400 N (4-800 Optional)
- Measuring accuracy DMS: ±1N (by 800 N ±2 N; 40 N ± 0,1N)
- Measuring accuracy Electronics/Mechanics: ±1N (by 800 N ±2 N; 40 N ± 0,1N)
- Measuring accuracy total: ±2 N (by 800 N ±4 N; 50 N ± 0,2N)
- Force increase DMS: 250 N/sec.
- Measuring Range (mass) : 10 - 50000mg (±1mg in stable environment, ±2 in unstable environment) measurement resolution 1mg
- Measuring Range (diameter) : 3 - 18 mm (±0.05mm) measurement resolution 0.01
- Measuring Range (thickness) : 3 - 12 mm (±0.05mm) measurement resolution 0.01
- Measuring unit: mm or inch
- Size: 49.5 x 62.4 x 545 (W x D x H cm)
- Weight: 42 kg (without Magazine feeder or Collector)
- Power requirements: 100-240 V, 50 Hz/60 Hz
- Language packages : English, Spanish, Dutch, Italian, French, Brazilian, Portuguese, Portuguese, Polish, Germany
